- Available brand
-
Titan C-Series
- Platform Rating
- 12,000 lbs.
- Platform Length
- 14' or 16'
The Titan C-Series offers a versatile roll-off system for chassis from 19,000 lbs. - 30,000 lbs. GVW. A wide range of body configurations and options such as a dock leveler are available. Miller Industries also produces a complete line of slide-back carriers.
Features
Standard
Frame Mounted Lifting System
- 2 Hydraulic Lift Cylinders
- Integrated Rear Body Locks
- Manual Driver Side Control Valve
- Fenders
- Mud Flaps
- Rear bumper
- Hydraulic Tank with Easy Service Filter
- Hydraulic pump
- 7 Way Tow Light Plug
- Back up Alarm
- Painted Black
- Assembled and Tested
Deck
- Steel Checker Plate Deck w/Full
- Cab Protector and Quick Attach System
- Outside Rub Rails with Stake Pockets
- Tapered Rear Approach Plate
- Front Chain Racks
- Removable Rear Wheels
- Painted Black
Optional
- Hydraulic Dock Leveler System
- Stationary Light Pylon
- 8,000 lbs. Electric Slide in Winch Package
- Tall Removable Sides (30" x 43.75")
- Short Removable Side (60" x 28.75")
- Extendable Hitch
- Pintle/Ball Attachment
- Hot Shift PTO
- Rear Work Lights
- Flashing LED Warning Light
- Tie-Down Chains
- Load Binders
- Switch Panel
- Aluminum Tool Boxes (33" or 49")
- Steel Tool Box with Stainless Steel Door (36" or 48")
- Rear Jumper Start Kit
- Additional Decks
- Installation
Specifications
Deck Specifications & Chassis Recommendation
| Deck Length | Capacity | G.V.W. | C.A. |
|---|---|---|---|
| 14' | 12,000 lbs. | 25,000 lbs. - 26,000 lbs. | 108" |
| 16' | 12,000 lbs. | 25,000 lbs. - 33,000 lbs. | 120" |
