Vulcan V-30 G2
Power, Performance, and Value
Vulcan pioneered integrated towing and recovery equipment in North America over a decade ago with the introduction of the Vulcan 940. That spirit of innovation is still found today in the Vulcan V-30 G2.
This versatile medium duty model is ideally suited to handle a wide range of vehicles from passenger cars, medium duty trucks, city tractors, and motor homes in both towing and recovery applications. Contact your local Vulcan Distributor to find out how the Vulcan V-30 G2 can help increase your profits by handling your tough business demands.
Features
Standard
- 120' CA or 136' CA Aluminum Modular Body
- Three Compartments Per Side
- Pass Thru Tunnel Box
- Lift Fork Storage, Driver & Passenger Side
- Adjustable Shelves
- Manual Contol - Driver's and Passenger Side
- Passenger Side Lanyard Control for Underlift
- Hydraulic Rear Jacks with Flipper Feet
- Tailboard D-Rings
- Safety Chains in the Tailboard
- Dual 15,000 lb. Planetary Winches
- Winch Air Free Spool
- 360° Sheave Heads
- Cable Tensioners
- Hydraulic Pump
- 4 Sets of Lift Forks
- 5,000 lb. & 6,500 lb. Strapless Wheel Retainers
- Chrome Latches with Keyless Lock/Unlock
- LED Body Lighting
- LED Tool Compartment Lighting
- Gas Door Shocks
- Mud Flaps
- Air and Electrical Hookups
Optional Equipment
- 120" or 138" VX2 Low Profile Body
- Light Pylon
- In Cab Controls
- Additional Lifting Attachments
- Wireless Remote
- Manual Extension Rear Outriggers
- Emergency Lighting
- Air Shift PTO
- Works Lights
- Wide Load Light Bar
- Hand Rails
- Installation
Specifications
Boom
| Retracted at 30° | 32,000 lbs. | |
| Extended at 30° | 12,000 lbs. | |
| Maximum Lift Angle | 36° | |
| Maximum Hook Height | 160” | |
| Reach Past Tailboard at 30° | 54” |
Underlift
| Retracted With Forks | 12,000 lbs. | |
| Extended With Forks | 8,500 lbs. | |
| Extended With Wheel Retainers | 5,000 lbs. / 6,500 lbs. | |
| Maximum Reach to Center of Forks at the Normal Tow Height | 84” | |
| Positive Tilt | 20° | |
| Negative Tilt | 10° | |
| Tow Rating | 32,000 lbs. |
Winch Rating & Cable
| Rating (first layer of drum) each Winch | 15,000 lbs. | |
| Diameter and Length (each winch) | 1/2" x 150' | |
| Cable Type | 6 x 37 IWRC |
Chassis Recommendation
| GVWR | 26,500 lbs. – 31,000 lbs. | |
| Maximum Frame Height | 40” | |
| Maximum Tire Size | 275/80 R 22.5 | |
| Minimum Cab to Axle (Clear) | 120" | |
| Maximum Cab to Axle (Clear) | 138' |
Important: All ratings are based on structural factors only, not vehicle capacities or capabilities. Specifications shown are approximations and may vary depending on chassis selected. Miller Industries Towing Equipment Inc. reserves the right to change or modify product and/or specifications without notice or obligation. Some equipment shown is optional.
