Features
Top of Page
Standard
- Full Size 84” Body
- Low Profile Aluminum Modular Body with Rubber Mounting Isolators
- 3 Compartments Per Side
- Manual Control - Driver & Passenger Side
- Lanyard Controls for Underlift & Boom on the passenger Side
- Chrome Double Action Latches with Keyless Lock and Unlock
- 4,000 lb & 6,000 lb L-Arms with Pivoting Receivers
- Dual 15,000 lb Planetary Winches
- Winch Air Free Spool
- Cable Tensioners
- 4 Sets of Lift Forks
- Low Profile Crossbar
- Safety Chains in Tailboard
- Hydraulic Rear Jacks w/Flipper Feet
- Gas Door Shocks
- Tailboard "D" Rings
- Federal Standard 108 Lighting
- LED Tool Compartment Lighting
- LED Body Lighting
- Cable Tiebacks
- 360° Sheave Heads
- Mud Flaps
- Air and Electrical Kit
- Quick Connect Air Supply
Optional
- Dual Reverse Cameras
- Manual Extension Rear Outriggers
- Seamless Toolbox Matting
- Airshift PTO
- Hot Shift PTO
- LED Work Lights
- SP 12,000 Sidepuller
- Light Pylon (Steel or Aluminum)
- Light Bar
- Wide Load Light Bar
- In-Cab Controls
- Additional Lifting Attachments
- Storage Options
- Installation
- Wireless Remote
- Underlift Tailboard Controls
- Chain Kit
- Endless Loop Strap Kit
Specifications
Boom
| Boom Rating |
Retracted |
32,000 lbs. |
| Boom Rating |
Extended |
12,000 lbs. |
| Maximum Angle |
|
36° |
| Maximum Hook Height |
|
160” |
| Maximum Reach Past Tailboard at 30° |
|
54” |
Underlift
| Fully Retracted |
With Forks |
12,000 lbs. |
| Fully Extended |
With Forks |
8,500 lbs. |
| Reach to Center of Fork Holder at Normal Tow Position |
|
84” |
| Positive Tilt |
|
20° |
| Negative Tilt |
|
10° |
| Tow Rating |
|
32,000 lbs. |
Winch Rating & Cable
| Rating (First Layer, Each Winch) |
15,000 lbs. |
|
| Diameter and Length (Each Winch) |
1/2” x 150’ |
|
| Type |
6 x 37 IWRC |
|
Chassis Recommendation
| GVWR |
26,500 lbs. – 31,000 lbs. |
|
| Minimum Cab to Axle (Clear) |
84” |
|
| Maximum Cab to Axle (Clear) |
138” |
|
| Maximum Frame Height |
40” |
|
| Maximum Tire Size |
275/70R22.5 |
|
Important: All ratings are based on structural factors only, not vehicle capacities or capabilities. Specifications shown are approximations and may vary depending on chassis selected. Miller Industries Towing Equipment Inc. reserves the right to change or modify product and/or specifications without notice or obligation. Some equipment shown is optional.
