ITEM |
PART NUMBER |
DESCRIPTION |
NUMBER REQUIRED |
|
1 |
68100 |
SLIDE CARRIAGE |
1 |
|
2 |
68200 |
L-BOOM |
1 |
|
3 |
7216142 |
LIFT CYLINDER |
2 |
|
4 |
7216141 |
POWER TILT CYLINDER |
2 |
|
5 |
68125 |
SLIDE CARRIAGE PIVOT PIN 1.975 x 22.938 |
1 |
|
6 |
68701 |
UNDERLIFT MOUNTING BRACKET |
2 |
|
7 |
81710 |
BOLT 7/8 x 2.25 COARSE THREAD |
6 |
|
8 |
83611 |
NUT 7/8 COARSE THREAD |
6 |
|
9 |
26306 |
PIN 1.480 x 20.875 SNAP-RING GROOVE |
1 |
|
10 |
68123 |
PIN 1.480 x 10625 SNAP-RING GROOVE |
1 |
|
11 |
86150E |
RETAINING RING 1.50 EXTERNAL |
4 |
|
12 |
64712 |
PIN .980 x 7 SNAP-RING GROOVE |
2 |
|
13 |
86100E-1 |
RETAINING RING 1.00 EXTERNAL |
4 |
|
14 |
65714 |
PIN .980 x 7 SNAP-RING GROOVE |
2 |
|
15 |
83100I |
RETAINING RING 1.00 INTERNAL |
4 |
|
16 |
68231 |
SHIM PAD 1/2 x 2.5 x 6.5 |
1 |
|
17 |
812A7 |
BOLT 3/8 x 3/4 COARSE THREAD BUTTON HEAD |
2 |
|
18 |
83311 |
FLAT WASHER 3/8 ID x 9/16 OD |
2 |
|
19 |
61735 |
WEAR PAD 2.5 x 3 NYLATRON |
2 |
|
20 |
68130 |
WEAR STRIP 3.8 x 2.75 x 32.75 |
4 |
|
21 |
812F0 |
FLAT HEAD SCREW 5/16 x 1 |
20 |
|
22 |
812F1 |
FLAT HEAD SCREW 5/16 x 1.5 |
4 |
|
23 |
83120 |
NYLON LOCK NUT 5/16 |
24 |
